Description
| Size Chart |
SMALL |
MEDIUM |
LARGE |
| RIDER HEIGHT | 5’1″-5’4″ | 5’4″-5’7″ | 5’7″-6’1″ |
| SEAT TUBE LENGTH | 15.5″ | 17.5″ | 18.5″ |
| WHEEL SIZE | 27.5″ | 27.5″ | 27.5″ |
Note: If you are in between sizes, measure your wingspan. If it is greater than your height, go for the frame size up. If your height is greater than your wingspan, go for a frame size down.
Geometry
| A | B | C | D | E | F | G | H | I | J | K | L | M | ||
| Model | Size | Seat Tube Length | Seat Tube Angle | Effective Seat Tube Angle | Head Tube Length | Head Tube Angle | Effective Top Tube | BB Height | BB Offset | Chainstay Length | Wheelbase | Frame Reach | Frame Stack | Standover Height |
| Premier | Small (27.5″) | 406 | 73 | 73 | 100 | 69 | 570 | 299 | 47 | 430 | 1089 | 383.5 | 610 | 713 |
| Medium (27.5″) | 456 | 73 | 73 | 100 | 69 | 585 | 299 | 47 | 430 | 1109 | 398.5 | 610 | 753 | |
| Large (27.5″) | 506 | 73 | 73 | 105 | 69 | 605 | 299 | 47 | 430 | 1107 | 417 | 615 | 793 |
