Description
S | M | M | L | XL | |
Wheel Size | 27.5″ | 27.5″ | 29″ | 29″ | 29″ |
Rider Height | 5’1″- 5’5″ | 5’5″ – 5’8″ | 5’5″ – 5’9″ | 5’9″ – 6’2″ | 6’2″ – 6’4″ |
(A) Stack | 582.6 | 582.6 | 582.6 | 591.8 | 591.8 |
(B) Reach | 425 | 445 | 445 | 465 | 485 |
(C) Head Tube Angle | 67° | 67° | 67° | 67° | 67° |
(D) Head Tube Length | 102 | 105 | 102 | 112 | 122 |
(E) Seat Tube Angle | 70° | 70° | 68° | 68° | 68° |
Seat Tube Angle Effective | 75° | 75° | 76° | 76° | 76° |
(F) Seat Tube Length | 395 | 435 | 435 | 487 | 522 |
(G) Top Tube Effective | 572 | 595 | 603 | 624 | 646 |
(H) Bottom Bracket Height | 326 | 326 | 326 | 326 | 326 |
(I) Bottom Bracket Offset | 27 | 27 | 47 | 47 | 47 |
(J) Chainstay | 432 | 432 | 436 | 436 | 436 |
(K) Wheel Base | 1133 | 1157 | 1165 | 1189 | 1213 |
(L) Standover Height | 676.8 | 703.8 | 703.8 | 740.6 | 757.5 |
Handlebar Width | 760 | 760 | 760 | 760 | 760 |
Stem Lenght | 45 | 45 | 45 | 45 | 45 |
Crank Lenght | 170 | 170 | 170 | 175 | 175 |
Dropper Post Travel | 150 | 150 | 150 | 170 | 170 |
Front Travel | 120 | 120 | 120 | 120 | 120 |
Rear Travel | 120 | 120 | 120 | 120 | 120 |
Fork Offset | 42 | 42 | 46 | 46 | 46 |
