Description
-
FramesetForkFrame ColorDecal Color
- Drivetrain
ShifterCrankCassetteRear DerailleurBBChainPedal
- Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
- Wheel & Tire
Wheel SetWheel SizeTireRimHubSpokes
- Brake
Brake LeverBrake CaliperRotor
XS S M L XL Height (cm) 154-164 162-170 168-176 174-181 180-187 Seat Tube Length (A) 450 470 500 520 550 Seat Tube Angle (B) 75 74.5 74 73.5 73 Effective Seat Tube Angle (C) 75 74.5 74 73.5 73 Head Tube Length (D) 90 105 130 155 185 Head Tube Angle (E) 72 72.5 73 73 73 Effective Top Tube (F) 515 525 540 555 570 Bb Height (G) 272 272 274.5 274.5 277 Bb Offset (H) 72.5 72.5 70 70 67.5 Chainstay Length (I) 415 415 415 415 415 Wheelbase (J) 975.54 977.32 984.83 995.01 1005.89 Frame Reach (K) 374.69 379.69 384.7 389.7 394.7 Frame Stack (L) 518.54 533.48 548.8 563.79 579.17 Standover Height (M) 722.25 744.47 762.86 784.67 806.2
